RECESSED LINEAR OFFICE LIGHT

Receessed linear luminaires for continous uniform illumination

RECESSED LINEAR OFFICE LIGHT
PRODUCT LOG
ARCHIVE VER: 2026.01
NODE ID: #0035

Technical Analysis & System Configuration

Comprehensive specification matrix and operational blueprints loaded from certified databases.

PRODUCT BENEFITS

  • Soft light beam for high visual comfort
  • Streamline design style, can be seamless connection with any dimension, with an elegant presentation
  • Can be grouped into different patterns to match the architecture style
  • Different dimming modes: 0-10V, DALI, Triac, RGBW
  • Different profile sizes are available to well lit up the space

SPECIFICATIONS & DIMENSIONS

MODEL NO POWER (W) LUMENS (LM) EFFICIENCY (LM/W) SIZE A (mm) B (mm) C (mm) CUTOUT (mm)
OS-LMOR-L1200 40W 4000 lm 100 lm/w 4ft / 1.2m 1200 76 40 60

PRODUCT FEATURES

  • Standard CCT: 3000K, 4000K, 6500K
  • Beam Angle: 120°
  • High Color Rendering: CRI > 80
  • High Power Factor: Pf > 0.9
  • Types of Protection: IP20
  • Long >50,000 hours lamp lifetime
  • Operates at 220-240VAC 50/60Hz
  • Class I Equipment
  • Product is made up of Die-casting Aluminum
  • Trimless version is also available
  • Application: Offices, retail outlets, supermarket, public areas, etc.
