Osaka LL0126S / LL0126M LED Linear Light Series 32W to 80W

A versatile LED linear light series delivering bright and consistent illumination from 32W to 80W. Designed for modern interiors, offices, and commercial environments with efficient, reliable, and long lasting lighting performance.

Model Input Voltage(V) Power CRI CCT(K) PF Efficacy (LM/W) LED Beam (degree) Installation Material Size(mm) D*W*H Size(Inch) D*W*H
LL0126S-32W AC220-240V
or
AC120-277V
50/60Hz
32W ≥80
or
≥90
3000K/
4000K/
5000K
≥0.9 70lm/w Samsung 300 Suspended Alu+PC D600×35×32 D23.6×1.4×1.3
LL0126S-40W 40W D900×35×32 D35.4×1.4×1.3
LL0126S-70W 70W D1200×35×32 D47.2×1.4×1.3
LL0126S-80W 80W D1500×35×32 D59.1×1.4×1.3
LL0126M-32W AC220-240V
or
AC120-277V
50/60Hz
32W ≥80
or
≥90
3000K/
4000K/
5000K
≥0.9 70lm/w Samsung 300 Mounted Alu+PC D600×35×32 D23.6×1.4×1.3
LL0126M-40W 40W D900×35×32 D35.4×1.4×1.3
LL0126M-70W 70W D1200×35×32 D47.2×1.4×1.3
LL0126M-80W 80W D1500×35×32 D59.1×1.4×1.3
